Carbon Steel Pipe Fittings
Arrow Piping Solutions is a trusted supplier, manufacturer, and exporter of a wide range of Carbon Steel Pipe Fittings, including ASTM A420 LTCS Pipe Fittings, ASTM A860 WPHY 42, 52, 60, 65 & 70 High Yield Butt-Welding Fittings, Carbon Steel 45° Elbow, CS Pipe Cap, Carbon Steel 90° Elbow, Carbon Steel Reducer, and more.
We are among the leading Carbon Steel Pipe Fittings Suppliers in India, providing products such as Buttweld Cross, Seamless Pipe Fittings, Welded Pipe Fittings, and Pipe Bends in Mumbai. We offer competitive pricing for ASME SA234 Carbon Steel Pipe Fittings across India, and we are a trusted Carbon Steel Pipe Elbow Exporter worldwide.
Arrow Piping Solutions acts as a one-stop solution for all industrial piping needs. We ensure timely delivery and consistent inventory to meet urgent project requirements. Our Carbon Steel Pipe Fittings are available in various sizes, wall thicknesses, and dimensions as per ASME/ANSI B16.9, B16.25, B16.28, B16.49, and MSS-SP-43 standards.
Supported by skilled machinists and quality analysts, we maintain top-notch product standards. We strictly follow international quality regulations and ensure every product meets project specifications. These pipe fittings are designed to perform reliably across various industries such as shipbuilding, oil & gas, chemical processing, power plants, and water treatment facilities.
Our fittings are ideal where extreme corrosion resistance is not critical. All products are securely packed using bubble wrap or wooden crates to avoid any damage such as dents, rusting, or deformation during transit.
Specifications of Carbon Steel Pipe Fittings
| Specification | ASTM/ASME A234 WPB / A860 – MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70 |
|---|---|
| Dimension Standards | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| ASME B16.9 | Factory-Made Wrought Buttwelding Fittings |
| ASME B16.25 | Buttwelding Ends |
| ASME B16.28 | Butt-Welded Short Radius Elbows & Returns Bends |
| MSS SP-43 | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications |
| Size Range | ½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) |
| Seamless Butt Weld Fitting Size | 1/2" - 10" |
| Welded Butt Weld Fitting Size | 1/2" - 48" |
| Thickness | Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Type | Seamless / Welded / Fabricated |
At Arrow Piping Solutions, we are equipped with advanced manufacturing machines, tools, and laboratory support that enable us to produce high-quality products. Each batch of Carbon Steel Pipe Fittings undergoes rigorous testing to ensure mechanical and physical strength. Additionally, we conduct third-party inspections and cross-verifications through authorized laboratories to maintain the highest standards.
Arrow Piping Solutions also provides various essential documents such as test reports, certificates, warranty letters, packing lists, and more. These documents enhance customer trust in our products and services. Our team of production experts is always available to offer comprehensive support to our clients for every product we supply.
Dimensions of Carbon Steel Pipe Fittings
| Nominal Pipe Size (NPS) | O.D. at Bevel (1), (2) | I.D. at End (1), (3), (4) | Wall Thickness (3) | Centre-to-End (A, B, C, M) | Centre-to-Centre (O) | Back-to-Face (K) | Alignment of Ends (U) | Overall Length (H) | Overall Length (E) |
|---|---|---|---|---|---|---|---|---|---|
| ½ to 2½ | 0.06 -0.03 | 0.03 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
| 3 to 3½ | 0.06 | 0.06 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
| 4 | 0.06 | 0.06 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
| 5 to 8 | 0.09 -0.06 | 0.06 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.25 |
| 10 to 18 | 0.16 -0.12 | 0.12 | Not less than 87.5% of nominal thickness | 0.09 | 0.38 | 0.25 | 0.06 | 0.09 | 0.25 |
| 20 to 24 | 0.25 -0.19 | 0.19 | Not less than 87.5% of nominal thickness | 0.09 | 0.38 | 0.25 | 0.06 | 0.09 | 0.25 |
| 26 to 30 | 0.25 -0.19 | 0.19 | Not less than 87.5% of nominal thickness | 0.12 | … | … | … | 0.19 | 0.38 |
| 32 to 48 | 0.25 -0.19 | 0.19 | Not less than 87.5% of nominal thickness | 0.19 | … | … | … | 0.19 | 0.38 |
