Inconel Valves
Arrow Piping Solutions offers a comprehensive range of Inconel Valves including Needle, Check, Butterfly, and Globe Valves. Recognized as a superalloy, Inconel—especially grades like Inconel 600 and Inconel 625—is a nickel-chromium based alloy known for its high resistance to corrosion, extreme temperature stability, and superior mechanical strength. Our Inconel valves are manufactured to meet the highest quality standards and are widely used in high-stress and corrosive applications across industries.
Used in extreme operating conditions, the Inconel Instrumentation and Pneumatic Valves offered by Arrow Piping Solutions are capable of withstanding both cryogenic and elevated temperatures. From the LS3 Exhaust Valves to Alloy 625 Needle Valves, our range delivers exceptional resistance to oxidation, pitting, crevice corrosion, and stress corrosion cracking.
Arrow Piping Solutions stocks and supplies valves under ASTM, ASME, and API standards in sizes ranging from 1/2″ to 4″ (DN25-DN200) with a wide variety of end connections, pressure classes, and functionalities.
Inconel Valve Specifications
| Grades | Inconel 600 (UNS N06600), Inconel 625 (UNS N06625) |
|---|---|
| Standard | ASTM A494 CY40 / CW6MC, ASME B16.34 |
| Size | 1/2″ to 4″ (DN25-DN200) |
| Thread Types | NPT, BSPP, G |
| Connection | Welded, Socket, Flanged, Clamped, Threaded |
| Operation | Manual, Electric, Pneumatic |
| Seal Material | PTFE, PPL, Soft Graphite |
| Leakage Rate | Soft Seal: Zero leakage, Hard Seal: ≤ Rated Flow 10⁻⁵ |
| Working Pressure | Up to 10000 psig / 689 bar |
| Functionality | 2-Way, 3-Way, 4-Way, 5-Way, Diverter |
| Manufacturing | Forged Bar Stock |
| Applicable Standards | ASME B16.5, B16.10, MSS SP-55, API 6D, API 598 |
Inconel Valve Sizes & Pressure Ratings
Process Control Valve Sizes:
- Size: 1/2" to 4" (DN25-DN200)
- Thread: NPT, PT, BSPP, G
- Connection: Welded, Socket, Flanged, Threaded, Clamped
- Pressure Class: PN10/16, Class 2500 - 6000 psig, Class 4500 - 10000 psig
Equivalent Grades
| Alloy | UNS Number | Forging | Casting | Barstock |
|---|---|---|---|---|
| Alloy 800 | N08800 | B564 N08810 | - | B408 N08800 |
| Alloy 825 | N08825 | - | - | B425 N08825 |
| Alloy 600 | N06600 | B564 N06600 | A494 CY40 | B166 N06600 |
| Alloy 625 | N06625 | B564 N06625 | A494 CW6MC | B446 N06625 |
Inconel Valves Applications
Arrow Piping Solutions supplies Inconel Valves to diverse industries such as:
- Nuclear Power
- Petrochemical Industry
- Chemical Processing
- Aerospace
- Marine Industry
- Pharmaceuticals
- Dairy and Food Processing
- Oil and Gas
- Modern Architecture
- Cosmetic and Beverage Sector
- Water Waste Treatment
- Heat Exchangers
- Power Generation
- Instrumentation Systems
Arrow Piping Solutions is a trusted alternative to global brands like Swagelok and Parker, offering leak-proof, precision-engineered Inconel Valves at competitive prices with guaranteed performance.
