Super Duplex Steel S32750 Forged Fittings
Arrow Piping Solutions is a leading manufacturer and supplier of premium quality Super Duplex Steel S32750 Forged Fittings. These fittings offer superior mechanical strength, excellent corrosion resistance, and durability in harsh environments, making them ideal for high-pressure and high-temperature industrial applications.
Our Super Duplex S32750 Forged Fittings are engineered using top-grade raw materials and advanced technology. These products are well-known for their robustness, weldability, pitting resistance, and low maintenance. Arrow Piping Solutions ensures that every fitting complies with international quality standards and is thoroughly tested for reliability and longevity.
Super Duplex Steel S32750 Forged Fittings Range:
- S32750 Super Duplex Steel Socketweld 45° Elbow
- Super Duplex S32750 Forged Coupling
- Super Duplex Steel S32750 High Pressure Forged Pipe Fittings
- ASTM A182 Super Duplex S32750 Threaded Union
- Super Duplex SAF 2507 Hex Bushing
- Super Duplex Steel S32750 Plug
- Super Duplex Steel S32750 Screwed Half Coupling
- Super Duplex Steel S32750 Threaded Elbow
- Super Duplex Steel S32750 S/W Reducing Tee
- Super Duplex S32750 90° Socket Weld Cross
- Super Duplex Steel S32750 Threaded Cap
Specifications
| Specification | ASTM A182 / ASME SA182 |
|---|---|
| Dimension Standards | ASME B16.11, MSS-SP-79, MSS-SP-83, MSS-SP-95, MSS-SP-97, BS3799 |
| Size Range | 1/8" NB to 4" NB |
| Type | Socketweld, Screwed-Threaded (NPT/PT) |
| Pressure Rating | Threaded: 2000 / 3000 / 6000 LBS Socketweld: 3000 / 6000 / 9000 LBS |
Equivalent Grades
| Standard | WERKSTOFF NR. |
|---|---|
| S32750 | 1.4462 |
Arrow Piping Solutions ensures that Super Duplex Forged Fittings are manufactured according to international specifications and suited for critical industrial applications.
Chemical Composition (%):
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
|---|---|---|---|---|---|---|---|---|---|---|
| S32750 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 22.0 – 23.0 | 3.0 – 3.5 | 4.50 – 6.50 | 0.14 – 0.20 | 63.72 min |
Mechanical Properties
| Grade | Density (g/cm³) | Density (lb/in³) | Melting Point (°C) | Melting Point (°F) |
|---|---|---|---|---|
| S32750 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
Manufacturing Standards
| ASTM A182 – ASME SA182 | Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings |
| ASME B16.9 | Factory-Made Wrought Buttwelding Fittings |
| ASME B16.11 | Socket Welding and Threaded Forged Fittings |
| MSS SP-43 | Low Pressure Corrosion Resistant Applications |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
| BS3799 | Screwed & Socket-welding Fittings for Petroleum Industry |
Applications of Super Duplex S32750 Forged Fittings
- Chemical Industry
- Petrochemical Industry
- Marine & Power Transmission Industry
- Power Plants
- Energy Industries
- Pharmaceutical Processing
- Modern Architecture
- Home Appliances
- Water Waste Projects
- Synthetic Fiber Manufacturing
- Heat Exchangers
- Fluid Piping
- Dairy and Food Processing
- Furniture Industry
Arrow Piping Solutions delivers Super Duplex S32750 Forged Fittings with guaranteed performance, dimensional precision, and prompt delivery. Contact us for custom fittings and bulk orders along with full certification and documentation support.
