Cupro Nickel 70 / 30 Forged Fittings
Arrow Piping Solutions is a trusted manufacturer and supplier of Cu-Ni 70/30 Forged Fittings. Comprising 70% Copper and 30% Nickel, this alloy offers outstanding corrosion resistance, weldability, and mechanical strength, making it ideal for marine and industrial applications.
We offer a wide range of Cupro Nickel 70/30 Forged Fittings in varying sizes, dimensions, and customized specifications. These fittings demonstrate exceptional resistance to erosion, stress corrosion cracking, and are reliable up to temperatures of 300°C, making them suitable for highly demanding environments.
Cupro Nickel 70/30 Forged Fittings Range:
- Cupro Nickel 70/30 Socketweld 45° Elbow
- Copper Nickel 70/30 Forged Coupling
- Cu-Ni 70/30 Hex Bushing
- ASTM B467 Cupro Nickel 70/30 Threaded Union
- CuNi 70/30 High Pressure Forged Pipe Fittings
- Copper Nickel Alloy 70/30 Plug
- Cu-Ni 70/30 90° Socket Weld Cross
- Copper Nickel 70/30 Screwed Half Coupling
- Cu-Ni Alloy 70/30 Threaded Elbow
- Cupro Nickel 70/30 S/W Reducing Tee
- Cu-Ni Gr 70/30 Threaded Cap
Specifications
| Specification | ASTM B467 / ASME SB467 |
|---|---|
| Dimension Standards | ASME B16.11, MSS-SP-79, MSS-SP-83, MSS-SP-95, MSS-SP-97, BS3799 |
| Size Range | 1/8" NB to 4" NB |
| Type | Socketweld, Screwed-Threaded (NPT/PT) |
| Pressure Rating | Threaded: 2000 / 3000 / 6000 LBS Socketweld: 3000 / 6000 / 9000 LBS |
Equivalent Grades
| STANDARD | UNS | DIN |
|---|---|---|
| Cupro Nickel 70/30 | C71500 | 2.0882 |
Arrow Piping Solutions ensures safe packaging of Cu-Ni 70/30 Forged Fittings using quality materials like cartons, pallets, and wooden boxes to guarantee safe doorstep delivery across India and globally.
Chemical Composition of Cupro Nickel 70/30 Forged Fittings
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
|---|---|---|---|---|---|---|
| Cupro Nickel 70/30 | 65 min | 1.0 max | 0.05 max | 29-33 | 0.4 - 1.0 | 1.0 max |
Mechanical Properties of Cupro Nickel 70/30 Forged Fittings
| Density | Melting Point | Tensile Strength | Yield Strength (0.2% Offset) | Elongation |
|---|---|---|---|---|
| 0.323 lb/in³ at 68°F | 2260°F | 50000 psi | 20000 psi | 30% |
Manufacturing Standards
| ASTM B564 – ASME SB564 | Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings |
| ASME B16.9 | Factory-Made Wrought Buttwelding Fittings |
| ASME B16.11 | Socket Welding and Threaded Forged Fittings |
| MSS SP-43 | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
Applications of Cupro Nickel 70/30 Forged Fittings
- Chemical Industry
- Petrochemical Industry
- Marine & Power Transmission Industry
- Power Plants
- Energy Industries
- Pharmaceutical Processing
- Modern Architecture
- Home Appliances
- Water Waste Projects
- Synthetic Fiber Manufacturing
- Heat Exchangers
- Fluid Piping
- Dairy and Food Processing
- Furniture Industry
Arrow Piping Solutions is committed to delivering top-quality Cupro Nickel 70/30 Forged Fittings at competitive prices. Contact us for bulk orders, technical assistance, or customized fitting solutions tailored to your industry requirements.
