Monel Ball Valves
Arrow Piping Solutions is a renowned manufacturer and supplier of premium quality Monel Ball Valves in India. Designed for highly corrosive environments, these valves are manufactured using ASTM A494 Grade M35-1 materials to offer outstanding mechanical properties, especially in marine, chemical, oil & gas, and petrochemical industries. Monel Ball Valves offer high performance in both high-pressure and low-pressure applications.
One of the most notable features of Monel Ball Valves is their superior corrosion resistance. They remain unaffected by seawater, rapidly flowing brackish water, and steam. Furthermore, they demonstrate excellent resistance to stress-related corrosion cracking, particularly in freshwater. In de-aerated conditions, these valves can resist hydrochloric and hydrofluoric acids, making them ideal for critical applications.
Arrow Piping Solutions offers Monel Ball Valves in sizes ranging from 1/8" to 4" with NPT, BSPP, G, SAE, and ISO 6149 thread types. Designed as per international standards including ANSI, ASTM, and ASME, our Monel valves ensure leak-free operations and unmatched safety for instrumentation and hydraulic systems.
Monel Ball Valve Specifications
| Material Grades | Monel (UNS N04400), ASTM A494 M35-1 |
|---|---|
| Standards | ASME B16.34, API 6D, API 598, MSS SP-55, MSS SP-25 |
| Size Range | 1/8" to 4" (DN6–DN200) |
| Thread Types | NPT, BSPP, G, SAE, ISO 6149 |
| Connection Types | Welded, Socket, Clamped, Flanged, Threaded, Ferrule |
| Operation | Manual, Electric Actuator, Pneumatic |
| Pressure Ratings | 3000–6000 PSI (206–413 bar) |
| Seal Options | PTFE, PPL, Graphite |
| Leakage Rate | Soft Seal: Zero Leakage, Hard Seal ≤ Rated Flow 10⁻⁵ |
| Function Types | 2-Way, 3-Way, 4-Way, 5-Way, Diverter, Normally Closed, Normally Open |
| Manufacturing Method | Forged Bar Stock |
| Design Standards | BS 1868, ASME B16.10, ASME B16.5 |
| Test & Inspection | API 6D / API 598 / MSS SP-55 / MSS SP-25 |
Monel Ball Valve Material Grades
| Alloy | UNS Number | Forging | Casting | Barstock |
|---|---|---|---|---|
| Monel | N04400 | B564 N04400 | A494 M35-1 | B164 N04400 |
| Monel K500 | N05500 | - | - | B865 N05500 |
Types of Monel Ball Valves
- Instrumentation Ball Valve – 2 Way / 3 Way / 5 Way
- Compression End Ball Valve (Double / Twin Ferrule)
- Mini Ball Valve – 1/4” to 1/2” OD
- Flanged End Ball Valve – Series 150LB / 300LB / 600LB
- Swagelok-Type One-Piece Instrumentation Ball Valves
- High Pressure Actuated Ball Valves – 6000 PSI
- Lockable Female Ball Valve – Panel Mounted
Application Industries
Arrow Piping Solutions supplies Monel Ball Valves to a wide range of industries including:
- Oil & Gas
- Chemical Processing
- Marine Engineering
- Dairy and Cosmetics
- Pharmaceuticals
- Food & Beverage
- Cryogenics
- Water Waste Management
- Instrumentation Systems
- High-Pressure Fluid Systems
- Offshore Platforms
- Power Plants
- District Heating
- Petrochemical Industry
Arrow Piping Solutions offers a reliable alternative to Swagelok and Parker with its OS-LOK Monel Ball Valves. Tested for use with oil, water, air, and inert gas, our valves are 100% leak-free and available with rapid delivery from our Mumbai port.
