Incoloy 800 / 800H / 800HT Fasteners
Incoloy 800 / 800H / 800HT Fasteners is the highly demanding product in the industrial sector. The product contains individual components that make the product durable and robust to work in any operational conditions. We at Arrow Piping Solutions, manufacture, and supply Inconel 800/ 800H/ 800HT Fasteners by using high-quality raw materials. We design and develop products to match our customer's demands. We follow the national and international quality standards.
The raw material used gives superior strength and resistance to various oxidizing conditions. Arrow Piping Solutions import such the best quality raw material from nearby and authorized suppliers. We promise to offer the well-crafted and superior product within an affordable price range. Arrow Piping Solutions has a team of experts to work in various departments. We have a separate production unit where we use advanced production types of machinery and processes.
Arrow Piping Solutions carries a wide range of Incoloy 800 | 800H | 800HT fasteners in a variety of size, dimensions standards and tolerance to meet your project's needs—including fasteners in dimension as per ASME B1.1, ASME B18.2.1, ASME B18.2.2, ASME B18.2.8, ASME B18.6.3, ASME B18.21.1, ASME B1.13M Fasteners | DIN , ANSI, JIS, ASTM standards specifications | weight chart & thickness of Grade 800 / 800H / 800HT Incoloy fasteners.
Apart from this, to ensure the product quality in the house, Arrow Piping Solutions have a modular test laboratory where we use the automated testing tools. Micro and macro elements present in Incoloy 800 / 800H / 800HT Fasteners support to work smoothly even in a high-temperature range. Also, some other factors give a stable configuration during fluctuating work conditions. We offer these Inconel Alloy 800, 800H, 800HT Fasteners in customized sizes and shapes. Also, Arrow Piping Solutions, keep a stock of this in our inventory. It helps us to supply the product immediately.
.jpg)
Our produced product holds excellent ability to work in high temperature, oxidizing, carburization conditions also. Our product contains unique mechanical characteristics and available in desired specifications and shapes. Incoloy 800 / 800H / 800HT Fasteners undergo various processes like machining, welding, annealing before finishing. We make the product available to our domestic and international clients as well.
Incoloy 800 / 800H / 800HT Fasteners Specifications
Specification | ASTM A479, A276, B564, B408 / ASME SA276, SA479, SB564, SB408 |
---|---|
Dimension | DIN, ISO, ASTM, JIS, BS, GB, IS and all International Standards |
Size Range | M3 - M56 | 3/6" to 2" | Custom Sizes |
Length | 3 mm to 200 mm |
Incoloy 800 | 800H | 800HT Fasteners Equivalent Grades
STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
---|---|---|---|---|---|---|---|---|
Incoloy 800 | N08800 | 1.4876 | Z8NC32-21 | X10NiCrAlTi32-20 | NCF 800 | NA 15 | ЭИ670 | XH32T |
Incoloy 800H | N08810 | 1.4958 | Z8NC32-21 | X10NiCrAlTi32-20 | NCF 800H | NA 15(H) | ЭИ670 | XH32T |
Incoloy 800HT | N08811 | 1.4959 | - | X8NiCrAlTi32-21 | NCF 800HT | NA 15(HT) | ЭИ670 | XH32T |
Incoloy 800 | 800H | 800HT Fasteners Chemical Composition
Grade | Ni | Fe | Cr | Cu | Ti | Al | C | Mn | S | Si |
---|---|---|---|---|---|---|---|---|---|---|
Incoloy 800 | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .15-.60 | .15-.60 | .1 max | 1.5 max | .015 max | 1.0 max |
Incoloy 800H | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .15-.60 | .15-.60 | .05-.10 max | 1.5 max | .015 max | 1.0 max |
Incoloy 800HT | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .25-.60 | .85-1.20 | .06-.10 max | 1.5 max | .015 max | 1.0 max |
Incoloy 800 / 800H / 800HT Fasteners Mechanical Properties
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
---|---|---|---|---|
7.94 g/cm3 | 1350-1400 ℃ | Psi - 75,000 , MPa -520 | Psi - 30,000 , MPa - 205 | 30 - 35 % |
Incoloy 800 / 800H / 800HT Fasteners Application Industries
- Textile machinery
- Oil and gas industry
- Pulp and paper industry
- Power plants
- Energy industries
- Furniture
- Pharmaceutical processing industry
- Modern architecture
- Home appliances
- Water waste projects
- Synthetic fiber
- Heat exchanger
- Fluid piping
- Dairy and food processing
