Nickel 200 Flanges Exporter In India
Comprehensive Technical Export Guide to UNS N02200 / W.Nr. 2.4066 Nickel 200 Weld Neck, Slip-On, Blind, Socket Weld, Threaded & Lap Joint Flanges Manufactured by Arrow Piping India
Complete Metallurgical & Export Specification Guide for Nickel 200 Flanges (UNS N02200 Pure Nickel Flanges) Exported Worldwide by Arrow Piping
Sourcing high-performance, precision-forged high nickel alloy flange components requires partnering with a certified and experienced Nickel 200 Flanges Exporter In India. In critical processing environments—ranging from caustic soda evaporation plants and synthetic fiber production to halide processing and food handling—standard stainless steel flanges such as 316L or duplex alloys frequently suffer from caustic stress corrosion cracking or localized attack under concentrated alkaline conditions. Nickel 200 (UNS N02200 / W.Nr. 2.4066 / ASTM B564) represents commercially pure wrought nickel metallurgy. Engineered with a minimum 99.0% Nickel composition, Nickel 200 offers unmatched resistance to caustic alkalis and a broad spectrum of reducing chemicals.
As a leading manufacturer, stockist, and Nickel 200 Flanges Exporter In India, Arrow Piping specializes in supplying high-precision metric and imperial flanges designed to handle extreme operational pressures and highly corrosive caustic media. Operating from Mumbai, Maharashtra, we manufacture and export complete piping flange solutions—including weld neck, slip-on, blind, socket weld, threaded, lap joint, orifice, and custom CNC-machined forged flanges—to EPC contractors, stockists, and industrial clients across the GCC, Europe, Americas, and Asia-Pacific regions.
1. What Are Nickel 200 Flanges & Why Are They Essential?
Nickel 200 Flanges are critical mechanical connection components forged or machined from high-purity Nickel 200 forged stock or plate material. Unlike standard stainless steels, Nickel 200 is designed to maintain exceptional ductility, thermal conductivity, and ferromagnetic properties, providing superior performance in caustic environments.
The alloy contains minimum 99.0% Nickel along with controlled levels of iron, copper, manganese, silicon, and carbon. These intentional alloying limits impart extraordinary immunity to caustic alkalis across all concentrations and temperatures up to its limits, neutral and alkaline salt solutions, and dry halogens. When specified as Nickel Alloy 200 Flanges, these components deliver outstanding structural stability, preventing catastrophic leaks in high-risk piping networks.
2. International Manufacturing Specifications & Equivalent Standards
When procuring from a Nickel 200 Flanges Exporter In India, cross-verifying material specifications ensures complete alignment with project requirements, offshore standards, and international pressure vessel codes:
| Specification Standard | Applicable Product Category & Details |
|---|---|
| ASTM B564 / ASME SB564 | Standard Specification for Nickel Alloy Forgings (Weld Neck, Slip-On, Blind Flanges) |
| ASTM B162 / ASME SB162 | Nickel Plate, Sheet, and Strip for Plate Flanges |
| ASME B16.5 | Pipe Flanges and Flanged Fittings (NPS 1/2 through NPS 24 - Class 150 to 2500) |
| ASME B16.47 Series A & B | Large Diameter Steel Flanges (NPS 26 through NPS 60) |
| UNS Designation | UNS N02200 |
| Werkstoff Designation | W.Nr. 2.4066 |
| EN Standard Name | EN Ni 99.2 / EN 1092-1 Flanges |
| DIN Standard Equivalent | DIN 2527 (Blind), DIN 2633 (Weld Neck), DIN 2576 (Slip-On) |
| NACE Compliance | NACE MR0175 / ISO 15156 & NACE MR0103 (Alkaline & Chemical Environments) |
3. Chemical Composition Breakdown of Nickel 200 (UNS N02200)
The outstanding corrosion immunity and structural load capabilities of Nickel 200 flanges are governed by its precise chemical formulation:
| Chemical Element | Minimum (%) | Maximum (%) | Metallurgical Role & Engineering Benefit |
|---|---|---|---|
| Nickel (Ni) | 99.00% | — | Provides core metallic matrix; provides extreme resistance to caustic alkalis and reducing media. |
| Copper (Cu) | — | 0.25% | Maintains purity while maintaining solid-solution ductility. |
| Iron (Fe) | — | 0.40% | Maintains structural stability and strength without compromising corrosion resistance. |
| Manganese (Mn) | — | 0.35% | Improves forgeability and acts as a deoxidizer during processing. |
| Carbon (C) | — | 0.15% | Controlled to balance room-temperature strength and ductility up to 315°C (600°F). |
| Silicon (Si) | — | 0.35% | Enhances fluid fluidity during casting and melting operations. |
| Sulfur (S) | — | 0.01% | Strictly limited to prevent hot shortness and intergranular cracking during hot working. |
4. Mechanical & Physical Property Profile
Engineers specifying flanges for high-pressure chemical lines, pressure vessel nozzles, and process piping systems must verify load-bearing limits. As a trusted Nickel 200 Flanges Exporter In India, Arrow Piping ensures all exported batches meet or exceed the following mechanical standards:
| Mechanical / Physical Property | Metric Units (SI) | Imperial Units |
|---|---|---|
| Ultimate Tensile Strength (UTS) | 380 MPa (Min) | 55 ksi (Min) |
| 0.2% Proof Yield Strength | 103 MPa (Min) | 15 ksi (Min) |
| Elongation at Break (A5) | 40% (Min) | 40% (Min) |
| Hardness (Rockwell B / Brinell) | 70 HRB Max / 130 HBW Max | 70 HRB Max / 130 HBW Max |
| Charpy V-Notch Impact Energy (Room Temp) | 200 Joules (Avg Min) | 147 ft-lbs (Avg Min) |
| Density | 8.89 g/cm³ | 0.321 lb/in³ |
| Modulus of Elasticity (20°C) | 207 GPa | 30.0 x 10⁶ psi |
| Thermal Conductivity (at 100°C) | 70.2 W/m·K | 487 BTU-in/hr-ft²-°F |
| Electrical Resistivity | 0.096 µΩ·m | 58 ohm·circ mil/ft |
| Melting Point Range | 1435 – 1446 °C | 2615 – 2635 °F |
5. Deep-Dive Comparison: Nickel 200 vs. Nickel 201 vs. Stainless Steel 316L
Selecting the correct flange alloy prevents severe corrosion failures in aggressive chemical handling operations. Here is a quick metallurgical evaluation:
1. Nickel 200 (UNS N02200 / 2.4066):
Commercially pure wrought nickel with min 99.0% Ni and maximum 0.15% carbon. Excellent resistance to all concentrations of caustic soda, anhydrous ammonia, and dry halogens at temperatures below 315°C (600°F).
2. Nickel 201 (UNS N02201 / 2.4061):
Low-carbon version of commercially pure nickel restricted to max 0.02% carbon. Specifically formulated for operating temperatures above 315°C (600°F) to avoid intergranular graphitization that can occur in Nickel 200.
3. Stainless Steel 316L (UNS S31603 / 1.4404):
Standard austenitic stainless steel with 17% Cr, 12% Ni, and 2.5% Mo. While economical for general service, 316L rapidly succumbs to caustic stress corrosion cracking and pitting when exposed to hot concentrated alkaline environments.
6. Complete Range of Nickel 200 Flanges Exported by Arrow Piping
As a full-spectrum Nickel 200 Flanges Exporter In India, we manufacture and export an extensive catalog of standard, non-standard, and custom flanges manufactured strictly per ANSI, ASME, DIN, ISO, BS, and EN standards:
| Flange Category | Available Types & Configurations | Dimensional Standards |
|---|---|---|
| Nickel 200 Weld Neck Flanges (WNF) | Standard Bore, Extra Heavy Bore, Schedule 10S to SCH 160/XXS, Long Weld Neck (LWN) | ASME B16.5, ASME B16.47, DIN 2633, EN 1092-1 Type 11 |
| Nickel 200 Slip-On Flanges (SOF) | Raised Face (RF), Flat Face (FF), Ring Type Joint (RTJ), Hubbed Slip-On | ASME B16.5, DIN 2576, EN 1092-1 Type 12 |
| Nickel 200 Blind Flanges (BLRF) | Raised Face Blind, Flat Face Blind, Ring Type Joint Blind (RTJ), Spectacle Blind, Spacers & Paddle Blinds | ASME B16.5, ASME B16.48, DIN 2527, EN 1092-1 Type 05 |
| Nickel 200 Socket Weld Flanges (SWF) | Raised Face Socket Weld, Flat Face Socket Weld, High-Pressure SW Flanges | ASME B16.5, EN 1092-1 Type 14 |
| Nickel 200 Threaded Flanges (THDF) | NPT Threaded, BSPT Threaded, Male/Female Threaded Flanges | ASME B16.5, DIN 2566, EN 1092-1 Type 13 |
| Nickel 200 Lap Joint & Special Flanges | Lap Joint Flanges with Stub Ends, Orifice Flanges, Reducing Flanges, Custom CNC Machined Forged Rings | ASME B16.5, ASME B16.36, Custom Blueprints |
7. Pressure Class Ratings & Flange Facing Types for Nickel 200 Flanges
Because Nickel 200 retains high ductility and structural performance across pressure ranges, flanges are produced across comprehensive ASME pressure classes:
| ASME Pressure Class | DIN / EN Pressure Rating | Primary Flange Facing Types Available | Typical Application Environment |
|---|---|---|---|
| Class 150 | PN 6 / PN 10 / PN 16 | Raised Face (RF), Flat Face (FF) | Low-pressure caustic transfer lines, utility piping |
| Class 300 | PN 25 / PN 40 | Raised Face (RF), Tongue & Groove (T&G) | Medium-pressure process reactors, heat exchangers |
| Class 600 | PN 63 / PN 100 | Raised Face (RF), Ring Type Joint (RTJ) | High-pressure alkaline chemical processing |
| Class 900 | PN 160 | Ring Type Joint (RTJ), Male & Female (M&F) | High-pressure chemical reactor systems |
| Class 1500 | PN 250 | Ring Type Joint (RTJ) | Severe pressure halogen synthesis piping |
| Class 2500 | PN 400 | Ring Type Joint (RTJ) Heavy Duty | Ultra-high-pressure specialized processing lines |
*Assembly Note: When installing Nickel 200 flanges, ensure appropriate gasket selection (such as PTFE-envelope or Nickel 200 spiral wound gaskets with compatible anti-seize bolting) to prevent galvanic interaction and leakage.
8. Critical Industrial Applications Worldwide
As a leading Nickel 200 Flanges Exporter In India, Arrow Piping exports UNS N02200 flanges to high-stress industrial applications across the globe:
a) Caustic Soda Production & Alkaline Processing
Nickel 200 weld neck and slip-on flanges are extensively deployed in caustic evaporators, alkali storage tanks, and transfer piping. They resist caustic stress cracking and erosion-corrosion across high concentration sodium hydroxide (NaOH) streams.
b) Synthetic Fiber & Viscose Manufacturing
Manufacturing processes for viscose rayon and synthetic polymers involve highly corrosive alkaline baths and salts. Nickel 200 blind and lap joint flanges maintain absolute structural integrity without contaminating pure process streams.
c) Food Processing & Pharmaceutical Production
Due to its exceptional purity and resistance to product contamination, Nickel 200 flanges are used in high-purity food processing, fatty acid treatment, and pharmaceutical reaction vessels requiring product clarity.
d) Halogen Processing & Aerospace Components
Nickel 200 forged flanges offer outstanding resistance to dry fluorine and chlorine gases at elevated temperatures, making them critical for fluorochemical synthesis, missile hardware, and aerospace systems.
9. Comprehensive Quality Assurance, Testing & Export Traceability
At Arrow Piping, quality control is central to our manufacturing and export operations. Every export shipment of Nickel 200 flanges undergoes rigorous testing before dispatch to ensure zero site defects.
Our Rigorous QA/QC Testing Protocol Includes:
- PMI Testing (Positive Material Identification): 100% XRF spectro-analysis on all flange lots to verify min 99.0% Nickel composition.
- Dimensional & Facing Verification: Machining tolerance and flange face serration checks (125-250 AARH finish) per ASME B16.5 / B16.47.
- Non-Destructive Testing (NDT): Ultrasonic Testing (UT) for internal forging defects and Dye Penetrant Inspection (DP) for surface integrity.
- Corrosion Performance Testing: Chemical resistance checks to guarantee performance in alkaline and reducing environments.
- Hydrostatic Pressure Testing: Proof pressure testing of flange bodies to ensure zero leakage under rated pressure limits.
- Mechanical & Tensile Testing: Destruction tensile, yield, and hardness tests carried out per ASTM B564 / ASTM E8 standards.
- Mill Test Certification: Fully compliant EN 10204 3.1 certification accompanied by third-party inspection reports (TUV, DNV, SGS, BV, Lloyds).
10. Weight Estimation & Shipping Weight Formula for Nickel 200 Flanges
To assist logistics managers and structural piping engineers in estimating freight tonnage, use the accurate mathematical formula below for Nickel 200 steel flanges:
Formula for Approximate Plate Flange Weight:
Weight (kg) = [ π × (OD² - ID²) × Thickness × Density ] / 4000000
Where:
- OD = Flange Outer Diameter in mm
- ID = Flange Inner Bore Diameter in mm
- Thickness = Flange Total Thickness in mm
- Density = 8.89 g/cm³ (0.00000889 kg/mm³)
Engineering Note: For Weld Neck Flanges, include additional mass allowances for hub taper and raised face height.
11. Factors Influencing Nickel 200 Flanges Price & Export Costs
When requesting quotes from a Nickel 200 Flanges Exporter In India, several key technical factors influence the final unit price:
- Raw Material Market Tonnage: Pure nickel alloy costs fluctuate based on international LME prices of Nickel.
- Flange Type & Pressure Class: Higher pressure classes (Class 900 to 2500) and complex hub geometries (Weld Neck, Long Weld Neck) require more raw material forging weight and extended machining time.
- Forging vs. Plate Construction: Seamless forged flanges per ASTM B564 vs. cut plate flanges per ASTM B162.
- Inspection & Testing Requirements: Additional third-party witness testing (TUV, DNV, Bureau Veritas) or specialized non-destructive evaluations.
- Export Packaging Standards: Heavy-duty ISPM-15 certified wooden crates with vacuum anti-corrosion barrier wrapping and protective end caps.
Why Choose Arrow Piping as Your Nickel 200 Flanges Exporter In India?
Partnering with Arrow Piping as your preferred Nickel 200 Flanges Exporter In India delivers key commercial and engineering advantages:
- Extensive Ready Stock Inventory: Large export-ready stock of standard ASTM B564 UNS N02200 weld neck, slip-on, blind, and socket weld flanges for rapid dispatch.
- In-House Precision Machining: Advanced CNC vertical turning lathes (VTL) capable of custom serrations, heavy wall hubs, and special dimensions per customer drawings.
- Complete Export Documentation Support: EN 10204 3.1 MTC, Certificate of Origin (COO), Chamber of Commerce attestation, Bill of Lading, and customized packing lists.
- Seaworthy Protective Packaging: All exported flanges feature plastic flange face protectors, VCI anti-rust wrapping, and are packed securely in wooden cases built for oceanic transit.
Looking for a certified Nickel 200 Flanges Exporter In India? Request an Immediate Export Quote from Arrow Piping today. Send your detailed bill of materials and technical drawings to our export desk for factory pricing and fast global delivery.
12. Global Export Destinations & Supply Network
Arrow Piping routinely exports Nickel 200 high nickel alloy flanges from Mumbai, India, to major industrial centers around the world:
- Middle East & GCC Countries: United Arab Emirates (Dubai, Abu Dhabi), Saudi Arabia (Jubail, Yanbu), Qatar (Doha), Kuwait, Oman (Muscat), Bahrain.
- Europe: United Kingdom, Germany, Netherlands (Rotterdam), Italy, Norway (Stavanger), France, Spain.
- Americas: United States (Houston, New Orleans), Canada, Brazil, Mexico, Chile.
- Asia-Pacific & Africa: Singapore, Malaysia, Australia (Perth), South Africa, Nigeria, Vietnam, Indonesia.
Conclusion
Selecting a verified, highly capable Nickel 200 Flanges Exporter In India like Arrow Piping guarantees metallurgical compliance, precise dimensional tolerances, and dependable corrosion performance for your most demanding global projects. With exceptional ductility, severe caustic resistance, and complete international compliance certification, Nickel 200 flanges supplied by Arrow Piping offer ultimate operational reliability.
Contact our export engineering sales team today at inquiry@arrowpiping.co.in or explore our complete flanges product line on our Flanges Product Page.
